Product Details

IKO CR8-1BUUR Cam Follower and Track Roller - Stud Type

Brand Name IKO
Model Number CR8-1BUUR
Min.Order Quantity 1 pcs
Price Negotiable

Product Features

IKO CR8-1BUUR bearing Size Chart (mm/inches)

d17 mm
D35 mm
B10 mm
d121.3 mm
D131 mm
rs min0.3 mm
Radial clearance classCN
Mass0.04 kg
Dynamic load, C5.9 kN
Static load, C03.3 kN
Fatigue limit load, Cu0.18 kN
f014.5
Nlim13,000 rpm
Min operating temperature, Tmin-20 °C
Max operating temperature, Tmax120 °C
Characteristic cage frequency, FTF0.41 Hz
Characteristic rolling element frequency, BSF5.38 Hz
Characteristic outer ring frequency, BPF04.1 Hz
Characteristic inner ring frequency, BPFI5.9 Hz
da min19 mm
da max21.3 mm
Da max33 mm
ra max0.3 mm

IKO CR8-1BUUR  Cam Follower and Track Roller - Stud Type

IKO CR8-1BUUR Cam Follower and Track Roller - Stud Type Cad Models
